The Advanced Control Group of the UPV/EHU's Department of Systems Engineering and Automation has developed a control system designed to ensure that photovoltaic generators always work at their maximum power point by adapting them in terms of the level of irradiance received from the sun and the load connected to the system. This constitutes an improvement in the efficiency of photovoltaic generators with respect to current control systems, although it also requires the use of more powerful processors and elements and therefore more expensive ones.
Electronic control to ensure photovoltaic systems always work at maximum power
Researchers at the UPV/EHU-University of the Basque Country have managed to maintain the maximum power point of solar panels despite changes in irradiation and load
First publication date: 27/03/2017
After having developed various algorithms and control systems and having applied them in a whole range of fields, such as robotics, control of motors in electric machines, and in wind generators, the UPV/EHU's Advanced Control Group has proven that one of the methods, a sliding mode controller, offers good results in the control of photovoltaic generators, too. "It's a kind of innovative, smart control that is robust in various environmental conditions. What is more, we have conducted the tests using commercial photovoltaic panels, so it could be applied in the sector directly," explained Oscar Barambones, head of this group's research area.
The main advantage offered by this new control system over the control systems that are fitted to current generators is that "it allows the generators to work at their maximum power point all the time, at their optimum working point and thus renders them more efficient. Current control systems tend to use algorithms of a perturbation/observation type, which cause the working point of the photovoltaic generator to be continually oscillating, so it does not work exactly at the maximum working point but is oscillating around this point, which causes its efficiency to diminish," remarked Barambones.
Sliding control is "appropriate", according to Barambones, for systems that have uncertainties such as photovoltaic generators: "the irradiance is not always the same, clouds may pass by, etc. or the load connected to the generator may also change. Owing to its characteristics, this type of control is capable of superimposing these uncertainties and adapting the generator's working point to the conditions of each moment so that it always works at its optimum point".
The paradox of renewables
Despite the fact that the tests were carried out using commercial photovoltaic panels and could be implemented and used on an industrial scale without any problem, Barambones admits that the system has certain features that "could slow down its transfer to the market". One thing is the cost, which is higher than that of the current controllers given that they have a "greater computational cost, in other words, they cannot be implemented using low-cost processors, and that is why processors with a greater calculating capacity are needed. So in many cases even the processor would need to be substituted. What would remain to be done is to calculate the cost difference involved and the percentage of efficiency that would increase when these new control modes are implemented".
Barambones explains the paradox that exists with renewable energies in this respect: "One may not be interested in having a more efficient photovoltaic generator if, for example, the cost of substituting the control mode of a photovoltaic generation system is going to be higher than adding additional panels, since the solar energy is available and costs nothing. Increasing the efficiency of a diesel generator, for example, thus enabling you to use less fuel to generate the same quantity of electrical power, is not the same as increasing the efficiency of a photovoltaic generator because what it uses is solar irradiation. You use less solar irradiation, it is true, but that is not such a critical aspect as in the case of fossil fuels".
This research work is the outcome of collaboration between the Advanced Control Group of the UPV/EHU's University School of Engineering in Vitoria-Gasteiz and the University of Gabès in Tunisia, through the co-supervision by Dr Oscar Barambones of the PhD thesis by Maissa Farhat, lecturer at the University of Gabès.
- A New Maximum Power Point Method Based on a Sliding Mode Approach for Solar Energy Harvesting Applied Energy, 185: 1185-1198 (2017) DOI: 10.1016/j.apenergy.2016.03.055
